|
性能项目
|
试验条件[状态]
|
测试方法
|
测试数据
|
数据单位
|
|
物理性能
|
SpecificGravity(Natural)
|
|
ASTMD792
|
1.20
|
g/cm3
|
|
密度(本色)
|
|
ISO1183
|
1.20
|
g/cm3
|
|
熔流率（熔体流动速率）(220°C/10.0kg)
|
|
ASTMD1238
|
39
|
g/10min
|
|
|
ISO1133
|
39
|
g/10min
|
|
收缩率-流动(3.20mm)
|
|
ASTMD955
|
0.25to0.50
|
%
|
|
MoldingShrinkage-AcrossFlow(3.20mm)
|
|
ASTMD955
|
0.30to0.55
|
%
|
|
收缩率
|
横向流量:3.20mm
|
ISO2577
|
0.30to0.55
|
%
|
|
流量:3.20mm
|
ISO2577
|
0.25to0.50
|
%
|
|
机械性能
|
拉伸模量2
|
|
ASTMD638
|
2100
|
MPa
|
|
拉伸模量
|
|
ISO527-2/50
|
2200
|
MPa
|
|
抗张强度2(屈服)
|
|
ASTMD638
|
57.0
|
MPa
|
|
拉伸应力(屈服)
|
|
ISO527-2/50
|
60.0
|
MPa
|
|
抗张强度2(断裂)
|
|
ASTMD638
|
57.0
|
MPa
|
|
拉伸应力(断裂)
|
|
ISO527-2/50
|
50.0
|
MPa
|
|
伸长率2(断裂)
|
|
ASTMD638
|
71
|
%
|
|
拉伸应变(断裂)
|
|
ISO527-2/50
|
52
|
%
|
|
弯曲模量3
|
|
ASTMD790
|
2400
|
MPa
|
|
弯曲模量4
|
|
ISO178
|
2320
|
MPa
|
|
弯曲强度3
|
|
ASTMD790
|
86.0
|
MPa
|
|
弯曲应力4
|
|
ISO178
|
88.0
|
MPa
|
|
冲击性能
|
CharpyNotchedImpactStrength5(23°C)
|
|
ISO179/1eA
|
24
|
kJ/m2
|
|
悬壁梁缺口冲击强度
|
23°C,3.18mm
|
ASTMD256
|
600
|
J/m
|
|
23°C,6.35mm
|
ASTMD256
|
170
|
J/m
|
|
悬壁梁缺口冲击强度5(23°C)
|
|
ISO180/1A
|
18
|
kJ/m2
|
|
硬度
|
洛氏硬度(R级)
|
|
ASTMD785
|
118
|
|
|
|
ISO2039-2
|
118
|
|
|
热性能
|
载荷下热变形温度(0.45MPa,未退火,6.40mm)
|
|
ASTMD648
|
93.0
|
°C
|
|
HeatDeflectionTemperature(0.45MPa,Unannealed,4.00mm)
|
|
ISO75-2/B
|
93.0
|
°C
|
|
载荷下热变形温度(1.8MPa,未退火,6.40mm)
|
|
ASTMD648
|
90.0
|
°C
|
|
HeatDeflectionTemperature(1.8MPa,Unannealed,4.00mm)
|
|
ISO75-2/A
|
90.0
|
°C
|
|
维卡软化温度
|
|
ISO306/B50
|
105
|
°C
|
|
可燃性
|
UL阻燃等级(0.8到3.0mm,全部)
|
|
UL94
|
V-0
|
