性能项目
|
试验条件[状态]
|
测试方法
|
测试数据
|
数据单位
|
|
物理性能
|
SpecificGravity(Natural)
|
|
ASTMD792
|
1.18
|
g/cm3
|
|
密度(本色)
|
|
ISO1183
|
1.18
|
g/cm3
|
|
熔流率（熔体流动速率）(220°C/10.0kg)
|
|
ASTMD1238
|
23
|
g/10min
|
|
|
ISO1133
|
23
|
g/10min
|
|
机械性能
|
拉伸模量
|
|
ISO527-2/50
|
2500
|
MPa
|
|
抗张强度2(屈服)
|
|
ASTMD638
|
62.0
|
MPa
|
|
拉伸应力(屈服)
|
|
ISO527-2/50
|
60.0
|
MPa
|
|
拉伸应力(断裂)
|
|
ISO527-2/50
|
48.0
|
MPa
|
|
弯曲模量3
|
|
ASTMD790
|
2400
|
MPa
|
|
弯曲模量4
|
|
ISO178
|
2450
|
MPa
|
|
弯曲强度3
|
|
ASTMD790
|
86.0
|
MPa
|
|
弯曲应力4
|
|
ISO178
|
88.0
|
MPa
|
|
冲击性能
|
CharpyNotchedImpactStrength5(23°C)
|
|
ISO179/1eA
|
44
|
kJ/m2
|
|
悬壁梁缺口冲击强度(23°C,3.18mm)
|
|
ASTMD256
|
590
|
J/m
|
|
悬壁梁缺口冲击强度5(23°C)
|
|
ISO180/1A
|
40
|
kJ/m2
|
|
硬度
|
洛氏硬度(R级)
|
|
ISO2039-2
|
118
|
|
|
热性能
|
HeatDeflectionTemperature(0.45MPa,Unannealed,4.00mm)
|
|
ISO75-2/B
|
93.0
|
°C
|
|
HeatDeflectionTemperature(0.45MPa,Annealed,4.00mm)
|
|
ISO75-2/B
|
98.0
|
°C
|
|
HeatDeflectionTemperature(1.8MPa,Unannealed,4.00mm)
|
|
ISO75-2/A
|
81.0
|
°C
|
|
HeatDeflectionTemperature(1.8MPa,Annealed,4.00mm)
|
|
ISO75-2/A
|
93.0
|
°C
|
|
维卡软化温度
|
--
|
ISO306/B50
|
98.0
|
°C
|
|
--
|
ISO306/B120
|
100
|
°C
|
|
RTIElec(1.5mm)
|
|
UL746
|
90.0
|
°C
|
|
RTIImp(1.5mm)
|
|
UL746
|
85.0
|
°C
|
|
RTIStr(1.5mm)
|
|
UL746
|
90.0
|
°C
|
|
电气性能
|
高电弧燃烧指数(HAI)(1.5mm)
|
|
UL746
|
PLC3
|
|
|
热丝引燃(HWI)(1.5mm)
|
|
UL746
|
PLC2
|
|
|
可燃性
|
UL阻燃等级
|
1.5mm
|
UL94
|
V-0
|
|
|
2.0mm
|
UL94
|
5VB
|
|
|
3.0mm
|
UL94
|
5VA
|
|
|
灼热丝易燃指数(1.0mm)
|
|
IEC60695-2-12
|
960
|
°C
|
|
热灯丝点火温度(1.0mm)
|
|
IEC60695-2-13
|
775
|
°C
|
